The Arjo Sara® Combilizer Full Standing Aid Patient Lift & Transfer with Full Recline will engage earlier mobilization of ventilated patients previously deemed high risk or inappropriate to mobilize, as well as patient with low attention and level of consciousness, poor trunk stability and hemofiltration lines in the groin.

A growing body of evidence supports the effectiveness of early mobilization. When utilized, early mobility is associated with reduced ICU and hospital length of stay and improved functional outcomes.

A review article on early mobilization in the ICU concluded: “A new approach for managing mechanically ventilated patients includes reducing deep sedation and increasing rehabilitation therapy and mobilization soon after admission to the ICU. Research provides preliminary evidence supporting the safety, feasibility and potential benefits of early mobilization in critical care medicine.”1

A standing or sitting position can deliver benefits that are vitally important in an optimized recovery process for a critically ill patient.

Sara Combilizer enables unconscious, sedated or mechanically ventilated patients to be mobilized in different standing or sitting positions for several hours per day.

The innovative design of Sara Combilizer provides a safe and secure platform so that patients can remain standing for the required amount of time to fully maximize early mobilization benefits.

Sara Combilizer provides this benefit in combination with a full range of patient positioning options, making it a comprehensive solution for early mobilization and related rehabilitation exercises.

Features & Benefits:

Supporting mobilization
Powered multifunctional positioning aid for early mobilisation and ICU rehabilitation of critically ill patients.
The advanced positioning possibilities of Sara® Combilizer help increasing comfort and preventing pressure ulcers by enabling easy repositioning.
Hand control operated positioning of patient between standing (75 degrees), sitting and supine position including the option of Trendelenburg positioning.
Height adjustable in stretcher and chair position as well as compact dimensions cater for an ergonomic working posture and good patient interaction.
Easy-to-read inclinometer indicating level of inclination when raising Sara Combilizer to a standing position.
Sideways tilting in all positions, for pressure re-distribution and rehabilitation purposes.
Reclining chair position for a comfortable resting position.
Safe Working Load 200kg (440lbs).
Designed to integrate to other Arjo lifting, transfer and mobilisation products, providing a complete mobilisation portfolio for critical care settings.
Comfort for the patient
Comfortable foam mattress and pillow with mattress cover in breathable, multidirectional stretch material.
The safety belt system secures the patient in a comfortable way.
Adjustable shoulder supports, foot plate, arm rests and lumbar support.
Designed for alternating patient posture.
Built-in Safety
Built-in pinch protection functions and emergency stops.
Intuitive hand control operation with two additional levels of control redundancy.
Easy to clean – designed for the ICU
Easy to clean surfaces designed to minimize dirt traps
No fastener strips or push buttons
Minimal use of zippers
Easy to remove, washable mattress, pillow and arm rest covers

Specifications

Additional Features

All patient positioning options powered and hand control operated.
Removable NiMH battery, to be charged in a separate charging station.
Inclinometer indicating the level of inclination.
Low friction castors, all with brakes.
Adjustable foot plate with anti-slip properties.
Adjustable arm-rests.
Adjustable lumbar support.
Adjustable and foldable shoulder supports.
Mattress covers in breathable fabric that provides multidirectional stretch.
Designed for easy cleaning and disinfection, with no fastener strips or push buttons.
Safety and emergency features
Adjustable safety belt system securing the patient at knee, hip and chest.
Three level redundant maneuvering controls for safety.
Manual “Quick-down” emergency lowering option from standing to lying position enabling CPR.
Built in pinch protection.
Dual emergency stops and system failure override.

Product Information
Max safe working load kg	200 kg
Max safe working load lb	440 lb
Weight kg	115 kg
Weight lb	265 lb
Width mm	750 mm
Width in	29,5 in
Max patient length cm	196 cm
Min patient length cm	148 cm
Chassis dimensions (incl. castors) mm	915 x 714 mm
Chassis dimensions (incl. castors) in	36 x 28 1/8 in
Max length (stretcher) mm	2045 mm
Max length (stretcher) in	80 1/2 in
Min length (chair incl. foot plate) mm	1580 mm
Min length (chair incl. foot plate) in	62 1/4 in
Max height (seat surface) mm	984 mm
Max height (seat surface) in	38 3/4 in
Min height (seat surface) mm	588 mm
Min height (seat surface) in	2,25 in
Turning radius, stretcher mm	2045 mm
Turning radius, stretcher in	80,5 in
Turning radius, chair mm	1840 mm
Turning radius, chair in	72,3 in
Max elevation, standing:	75°
Max sideways tilting:	20°
Trendelenburg tilt:	-15°
Electrical
Lifter protection class	IPX4
Handcontrol protection class	IPX6
Battery	NiMH, 2,5Ah, 24 V DC
